CSTSW Cast Steel Weldable Shut Off Valve for Ammonia, 1/2 to 12 Inch

Name: Ammonia Refrigeration Plant Turnkey Solutions
Brand: SUPER REFRIGERATION (INDIA) PVT. LTD.
Price: 5000.0 INR
Availability: InStock

Price 5000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

CSTSW Cast Steel Weldable Shut Off Valve for Ammonia, 1/2 to 12 Inch Specification

Valve Type
Globe / angle shut-off valve (SUPER type CSTSW)

Material
Cast steel (lost-wax cast)

Connection Type
Socket weldable

Sealing
Teflon (PTFE)

Usage
Industrial

Application
Ammonia (R717), R744 (CO2), HCFC and HFC refrigeration plants

Port Size
1/2" to 12" (15 mm to 300 mm)

Color
Golden (painted)

Expansion Option
Modular design for future expansion

Automation Level
Fully automatic / semi-automatic options

Plant Type
Turnkey Solution

Features
High efficiency, low operational cost, eco-friendly design

Safety Devices
Pressure relief valves, interlocks, gas leak detection system

Installation Time
As per project scope and capacity

Control Panel
PLC based with HMI

Material of Construction
Mild Steel / Stainless Steel

Power Supply
Three phase, 380-440 V, 50/60 Hz

Service Support
24/7 technical support available

Evaporator Type
Shell and Tube / Plate type

Condenser Type
Evaporative / Water cooled / Air cooled

Application
Industrial refrigeration for food processing, cold storage, beverage plants, and chemical industries

Cooling Capacity
Customizable as per requirement

Compressor Type
Screw and reciprocating compressors

Insulation
Premium grade PUF / EPS insulation available

Compliance Standards
Conforms to international safety and quality norms

Refrigerant
Ammonia (NH3)

About CSTSW Cast Steel Weldable Shut Off Valve for Ammonia, 1/2 to 12 Inch

The SUPER 1968 CSTSW is a cast-steel, Teflon-seat shut-off valve that is welded directly to steel ammonia (R717) piping, removing potential leaks at flanged or threaded joints. Bodies are made by the lost-wax casting process, and the top part can be replaced without any welding. Manufactured by the SUPER group; machined in-house at our Sonipat CNC plant.

Key features

Welded directly to steel piping, eliminating leaky flanges or threaded joints
Top part can be replaced easily with no welding
Bodies made by lost-wax casting
Linear flow pattern globe body with full-size ports for low pressure drop; accepts flow in either direction (straight type)
Non-metallic polymer seal, non-metallic front and back seating, Teflon tightening ring
Stem sealing with O-rings and ammonia glands; stainless-steel spindle

Specifications

Valve Type: Globe / angle shut-off valve (SUPER type CSTSW)
Port Size: 1/2" to 12" (15 mm to 300 mm)
Body Material: Cast steel (lost-wax cast)
Seat: Teflon (PTFE)
Connection Type: Socket weldable
Pressure: Safe working pressure 400 psig (27 bar)
Temperature Range: -51C to +116C (-60F to +240F)
Refrigerant: R717 (Ammonia), R744 (CO2), HCFC and HFC
Media: Ammonia (R717)
Color: Golden (painted)
Usage: Industrial

Why SUPER: SUPER has made valves since 1968 and is now in its third generation. SUPER REFRIGERATION (INDIA) PVT. LTD. also supplies the other equipment, controls and spares an ammonia plant needs, so you can source from one specialist supplier.

Send an enquiry with size, connection and quantity for a quotation.
Catalogue: https://www.super1968.com/super.pdf
Phone: +91-9811538277 | Email: info@super1968.com
Price shown is the list price for the smallest size (1/2"), ex-works, GST extra. Sizes above 8" on request.
